Collect your M-Bus meters and share measurement data to any superior system. MIVO Connect collects measurement values using open protocols.
An open M-Bus Gateway for measurement data collection for fixed or mobile 4G/5G networks. The device collects information through built-in or external interfaces such as M-Bus, M-Bus IP, Modbus RTU/TCP and others.
Read more
An add-on module to the MIVO Connect Data Gateway and extends the system's capacity with an additional 256 M-Bus meters.
Read more
An add-on module to the MIVO Connect Data Gateway and provides the system with the ability to collect wireless M-Bus meters.
Read more
Modular design
MIVO Connect is designed with a smart modular system that allows to be easily expanded with up to ten M-Bus Extender or Wireless M-Bus Extender, for collection of up to 2000 meters. MIVO Connect is completely open and you can freely choose how you want to export different measurement data to different systems simultaneously.
MIVO Connect OS
MIVO Connect's built-in web-based software makes it easy to manage all the properties meters and sensors. The intuitive wizard helps you quickly search for a meter or a list of meters. You get a good overview for checking if a meter is working and a snapshot of values for one or more meters.
Each scheduled export is completely individual and can be configured with different meters, delivery formats, collection resolution, and report intervals. The intelligent collection engine plans the collection in the most efficient way.
MIVO Connect supports the most common transport protocols: HTTP (S), FTP (S) and MQTT. The unit has predefined report formats and is regularly expanded with new formats.
The internal storage protects against data loss in case of problems with the internet connection or in case of possible data loss in overhead systems.
MIVO Connect has a full M-Bus decoder that has been tested over many years of operation against most meter manufacturers on the market. When delivered to overhead systems, metrics can be normalized to the desired unit and scaled which simplifies integration.
MIVO Connect can integrate with PLC via M-Bus over IP, ModBus RTU as well as ModBus TCP. The built-in web interface makes it easy to configure and generate modbus mappings and associated Excel documentation.
MIVO Connect has a smart modular system, which allows the device to be expanded with new physical interfaces or functions in the software as the future demands it.
